合肥方晶联合半导体有限公司

MOSFET

产品概述

方晶提供质量可靠、品种齐全、性能卓越的车规级功率器件，包含N型MOSFET，P型MOSFET，双通道MOSFET，IGBT，上述车规功率器件均已通过AEC-Q101认证。其中，车规级功率MOSFET器件电压覆盖范围为-150V至1050V,车规级IGBT器件电压覆盖范围为600V至1200V。基于先进的功率器件设计与晶圆制造技术，稳可靠的封装技术，优异的质量管控，我们致力于为客户提供“零”缺陷的汽车功率器件产品。

产品筛选

Product Name	Market Model	Technology	Product status	Product status	Product status	BV_DSS(V)	I_D(A)	I_D(A)	I_D(A)	I_D(A)	I_D(A)	I_D(A)
Reset all Download excel	工业级 Reset	Trench Reset	Production New Reset	SOT-23 SOP-8 DFN22 DFN33 DFN56 TO-252 TO-251S TO-263 TO-220 SOT-223 TO-220F TO-251 DFN3.33.3 DFN3.3X3.3 TO-252-2L DFN22-6L DFN 56 TO-220-3L Reset	P N Reset	-200.00 Reset	-130.00 Reset	-2.60 Reset	Reset	Reset	Reset	Reset

NCE2305A	工业级	Trench	Production	SOT-23	P	-12	-4.1	-0.7		29	7.8	1.7
NCE2333Y	工业级	Trench	Production	SOT-23	P	-12	-6	-0.7		19	12	1.8
NCE12P09S	工业级	Trench	Production	SOP-8	P	-12	-9	-0.7		11.5	35	2.5
NCE2301C	工业级	Trench	Production	SOT-23	P	-15	-2.6	-0.7		56	3.2	0.9
NCE2301A	工业级	Trench	Production	SOT-23	P	-15	-3	-0.7		46	9	1
NCE3417	工业级	Trench	Production	SOT-23	P	-15	-4.5	-0.7		28	8.1	1.7
NCE1013E*	工业级	Trench	Production	SOT-23	P	-20	-0.66	-0.6		362		0.3
NCE2301D	工业级	Trench	Production	SOT-23	P	-20	-2	-0.7		97	3	0.7
NCE2301F	工业级	Trench	Production	SOT-23	P	-20	-2	-0.7		88	2.9	0.7
NCE2301B	工业级	Trench	Production	SOT-23	P	-20	-2.6	-0.7		60	3.2	0.9
NCE2301E*	工业级	Trench	Production	SOT-23	P	-20	-2.6	-0.7		87	3.2	0.9
NCE2301	工业级	Trench	Production	SOT-23	P	-20	-3	-0.7		46	3.3	1
NCE2321	工业级	Trench	Production	SOT-23	P	-20	-3.9	-0.7		34	8.5	1.4
NCE3415*	工业级	Trench	Production	SOT-23	P	-20	-4	-0.65		29	10	1.4
NCE3415E*	工业级	Trench	Production	SOT-23	P	-20	-4	-0.7		29	11	1.4
NCE3415Y*	工业级	Trench	Production	SOT-23	P	-20	-4	-0.65		29	12	1.4
NCE2305	工业级	Trench	Production	SOT-23	P	-20	-4.1	-0.7		34	13.1	1.7
NCE2323	工业级	Trench	Production	SOT-23	P	-20	-4.1	-0.7		34	9	1.7
NCE2321A	工业级	Trench	Production	SOT-23	P	-20	-4.5	-0.6		31	15	1.9
NCE20P05Y	工业级	Trench	Production	SOT-23	P	-20	-5	-0.7		22	15	1.6
NCE20P07N	工业级	Trench	Production	SOT-23	P	-20	-7	-0.55		31	13	1.9
NCE20P10J	工业级	Trench	Production	DFN2*2	P	-20	-10	-0.85		19	34	3.5
NCE20P45Q	工业级	Trench	Production	DFN3*3	P	-20	-45	-0.6		5.8	63.5	80
NCE20P70G	工业级	Trench	Production	DFN5*6	P	-20	-70	-0.6		2.3	100	130
NCE20P85GU	工业级	Trench	Production	DFN5*6	P	-20	-85	-0.6		1.4	115	150
NCE2303	工业级	Trench	Production	SOT-23	P	-30	-2	-1.6	72	110	8.5	1
NCE3407	工业级	Trench	Production	SOT-23	P	-30	-4.1	-1.5	48	60	13	1.4
NCE3401	工业级	Trench	Production	SOT-23	P	-30	-4.2	-1	48	56	8.5	1.2
NCE3401Y	工业级	Trench	Production	SOT-23	P	-30	-4.2	-1	47	56	8.5	1.2
NCE3407A	工业级	Trench	Production	SOT-23	P	-30	-4.3	-1.5	42	50	14	1.5
NCE3407AY	工业级	Trench	Production	SOT-23	P	-30	-4.3	-1.5	40	46	14	1.5
NCE3401A	工业级	Trench	Production	SOT-23	P	-30	-4.4	-1	43	50	9.5	1.3
NCE3401AY	工业级	Trench	Production	SOT-23	P	-30	-4.4	-1	41	48	9.5	1.3
NCE9435	工业级	Trench	Production	SOP-8	P	-30	-5.1	-1.6	43	62	11	2.5
NCE9435A	工业级	Trench	Production	SOP-8	P	-30	-5.3	-1.6	37	60	12	2.6
NCE3007S	工业级	Trench	Production	SOP-8	P	-30	-6.5	-1.9	29	49	9.2	3.1
NCE30P06J	工业级	Trench	Production	DFN2*2	P	-30	-6.5	-1.3	24	34	9.2	2.8
NCE4435	工业级	Trench	Production	SOP-8	P	-30	-9.1	-1.5	16	21	30	3.1
NCE4435X	工业级	Trench	Production	SOP-8	P	-30	-10	-1.6	14	19	32	3
NCE30P10S	工业级	Trench	Production	SOP-8	P	-30	-10	-1.5	17.6	25.5	24	3
NCE30P12S	工业级	Trench	Production	SOP-8	P	-30	-12	-1.5	11.5	18	24	3
NCE30P15AS	工业级	Trench	Production	SOP-8	P	-30	-15	-1.25	8.5	11.5	48	3.1
NCE30P16Q	工业级	Trench	Production	DFN3*3	P	-30	-16	-1.6	13	22	31	30
NCE30P20Q	工业级	Trench	Production	DFN3*3	P	-30	-20	-1.6	11.5	18	45.6	35
NCE30P25Q	工业级	Trench	Production	DFN3*3	P	-30	-25	-1.7	8.9	15	46	35
NCE30P25S	工业级	Trench	Production	SOP-8	P	-30	-25	-1.5	6.4	8.3	98.9	3.5
NCE30P28Q	工业级	Trench	Production	DFN3*3	P	-30	-28	-1.7	6.7	9.5	30	30
NCE30P30K	工业级	Trench	Production	TO-252	P	-30	-30	-1.5	13	22	31	35
NCE30P30G	工业级	Trench	Production	DFN5*6	P	-30	-30	-1.6	7.4	10.6	81	45
NCE30P30L	工业级	Trench	Production	TO-251S	P	-30	-30	-1.6	13	22	31	60
NCE30P50G	工业级	Trench	Production	DFN5*6	P	-30	-50	-1.5	5.5	7	93	35
NCE30P55L	工业级	Trench	Production	TO-251S	P	-30	-55	-1.5	6.8	10	71	110
NCE30P60G	工业级	Trench	Production	DFN5*6	P	-30	-60	-1.5	3.2	4.5	138	70
NCE40P05S	工业级	Trench	Production	SOP-8	P	-40	-5.3	-1.9	67	92	14	2
NCE40P05Y	工业级	Trench	Production	SOT-23	P	-40	-5.3	-1.9	73	98	14	2
NCE40P06J	工业级	Trench	Production	DFN2*2	P	-40	-6	-1.6	29	34	23	2
NCE40P06S	工业级	Trench	Production	SOP-8	P	-40	-6	-1.9	40	47	19	2.2
NCE40P07S	工业级	Trench	Production	SOP-8	P	-40	-6.2	-1.7	16	21	24	2.5
NCE40P13S	工业级	Trench	Production	SOP-8	P	-40	-13	-1.7	12	15	40	3
NCE40P15K	工业级	Trench	Production	TO-252	P	-40	-15	-1.8	29	34	25	50
NCE40P20Q	工业级	Trench	Production	DFN3*3	P	-40	-20	-1.8	14	21.5	31	30
NCE40P25G	工业级	Trench	Production	DFN5*6	P	-40	-25	-1.8	11.5	19	31	50
NCE40P40K	工业级	Trench	Production	TO-252	P	-40	-40	-1.9	11.5	18.5	72	50
NCE40P40D	工业级	Trench	Production	TO-263	P	-40	-40	-1.9	10	12.5	72	50
NCE40P70K	工业级	Trench	Production	TO-252	P	-40	-70	-1.9	7.8	11.4	106	85
NCE55P05S	工业级	Trench	Production	SOP-8	P	-55	-5	-2.6	64		26	3
NCE55P15I	工业级	Trench	Production	TO-252	P	-55	-12	-2.6	60		26
NCE55P15K	工业级	Trench	Production	TO-252	P	-55	-15	-2.6	60		26	35
NCE55P15	工业级	Trench	Production	TO-220	P	-55	-15	-2.6	60		26	45
NCE55P30K	工业级	Trench	Production	TO-252	P	-55	-30	-2.6	30		56	65
NCE55P30	工业级	Trench	Production	TO-220	P	-55	-30	-2.6	30		56	90
NCE2309	工业级	Trench	Production	SOT-23	P	-60	-1.6	-2	140	160	11	1.5
NCE60P02Y	工业级	Trench	Production	SOT-23	P	-60	-2	-2	140	160	9	1.7
NCE60P03Y	工业级	Trench	Production	SOT-23	P	-60	-3	-2	66	78	14	1.7
NCE60P04Y	工业级	Trench	Production	SOT-23	P	-60	-4	-1.5	106	135	25	1.5
NCE60P04R	工业级	Trench	Production	SOT-223	P	-60	-4	-1.5	106	135	25	3.1
NCE60P04SN	工业级	Trench	Production	SOT-23	P	-60	-4	-1.5	106	135	25	2
NCE60P05N	工业级	Trench	Production	SOT-23	P	-60	-5	-1.5	55	75	16	3.1
NCE60P05R	工业级	Trench	Production	SOT-223	P	-60	-5	-1.5	55	75	16	3.1
NCE60P05BY	工业级	Trench	Production	SOT-223	P	-60	-5	-1.5	55	75	16	1.5
NCE60P07AS	工业级	Trench	Production	SOP-8	P	-60	-7	-1.5	55	70	16	3
NCE60P08AS	工业级	Trench	Production	SOP-8	P	-60	-8	-1.5	44	50	31	3
NCE60P09S	工业级	Trench	Production	SOP-8	P	-60	-9	-2.6	32		42.5	3
NCE60P09AS	工业级	Trench	Production	SOP-8	P	-60	-9	-1.75	30.5	37	41	3
NCE60P10K	工业级	Trench	Production	TO-252	P	-60	-10	-1.5	106	135	25	45
NCE60P12AS	工业级	Trench	Production	SOP-8	P	-60	-12	-1.8	11	13	62	3.5
NCE60P12K	工业级	Trench	Production	TO-252	P	-60	-12	-1.5	84	100	38	60
NCE60P16AK	工业级	Trench	Production	TO-252	P	-60	-16	-1.5	55	65	23	32
NCE60P16AQ	工业级	Trench	Production	DFN3*3	P	-60	-16	-1.5	55	65	23	30
NCE60P25	工业级	Trench	Production	TO-220	P	-60	-25	-2.6	39		46	90
NCE60P25K	工业级	Trench	Production	TO-252	P	-60	-25	-2.6	39		46	90
NCE60P28AK	工业级	Trench	Production	TO-252	P	-60	-28	-1.5	43	48	31	80
NCE60P40F	工业级	Trench	Production	TO-220F	P	-60	-40	-2.6	30		35	60
NCE60P45K	工业级	Trench	Production	TO-252	P	-60	-45	-2.6	31		35	110
NCE60P45AK	工业级	Trench	Production	TO-252	P	-60	-45	-1.8	30.5	37	37	100
NCE60P50	工业级	Trench	Production	TO-220	P	-60	-50	-2.6	23		75	95
NCE60P50K	工业级	Trench	Production	TO-252	P	-60	-50	-2.6	23		75	95
NCE60P55K	工业级	Trench	Production	TO-252	P	-60	-55	-2.6	20		50	110
NCE60P70D	工业级	Trench	Production	TO-263	P	-60	-70	-2.6	15.5		73	200
NCE60P82AK	工业级	Trench	Production	TO-252	P	-60	-82	-1.8	11	13	62	150
NCE60P82A	工业级	Trench	Production	TO-220	P	-60	-82	-1.8	11	13	62	150
NCE60P82AD	工业级	Trench	Production	TO-263	P	-60	-82	-1.8	11	13	62	210
NCE01P03S*	工业级	Trench	Production	SOP-8	P	-100	-3	-1.9	170	200	33	2.5
NCE01P05S*	工业级	Trench	Production	SOP-8	P	-100	-5	-1.9	85	95	70	3.1
NCE01P13*	工业级	Trench	Production	TO-220	P	-100	-13	-1.9	170	200	33	40
NCE01P13K*	工业级	Trench	Production	TO-252	P	-100	-13	-1.9	170	200	33	40
NCE01P18*	工业级	Trench	Production	TO-220	P	-100	-18	-1.9	85	95	70	70
NCE01P18K*	工业级	Trench	Production	TO-252	P	-100	-18	-1.9	85	95	70	70
NCE01P18L*	工业级	Trench	Production	TO-251S	P	-100	-18	-1.9	85	95	70	70
NCE01P18D*	工业级	Trench	Production	TO-263	P	-100	-18	-1.9	85	95	70	70
NCE01P30*	工业级	Trench	Production	TO-220	P	-100	-30	-1.9	44	48	136	120
NCE01P30K*	工业级	Trench	Production	TO-252	P	-100	-30	-1.9	44	48	136	120
NCE01P30I*	工业级	Trench	Production	TO-251	P	-100	-30	-1.9	44	48	136	120
NCE01P30L*	工业级	Trench	Production	TO-251S	P	-100	-30	-1.9	44	48	136	120
NCE01P30D*	工业级	Trench	Production	TO-263	P	-100	-30	-1.9	44	48	136	120
NCE15P25I*	工业级	Trench	Production	TO-251	P	-150	-25	-1.9	120	131	137	160
NCE15P25JK*	工业级	Trench	Production	TO-252	P	-150	-25	-1.9	120	131	137	160
NCE15P25*	工业级	Trench	Production	TO-220	P	-150	-25	-1.9			137	120
NCE15P25J	工业级	Trench	Production	TO-220	P	-155	-25	-1.9	120	131	137	160
NCE15P25JI	工业级	Trench	Production	TO-251	P	-155	-25	-1.9	120	131	137	160
NCE60P09K	工业级	Trench	Production	TO-252	P	-60	-9	-2			11.3	40
NCE40P20Q1	工业级	Trench	Production	DFN3.3*3.3	P	-40	-20	-1.8	14	21.5	54	30
NCE60PD05S	工业级	Trench	Production	SOP-8	P	-60	-5	-2.6	40		46.2	3
NCE1216	工业级	Trench	Production	DFN2*2	P	-12	-16	-0.7		11.5	35	2.5
NCE30P15S	工业级	Trench	Production	SOP-8	P	-30	-15	-1.5	8.5	11.5	48	3.1
NCE60P17AQ	工业级	Trench	Production	DFN3*3	P	-60	-17	-1.5	40	48	30	32
NCE3401BY	工业级	Trench	Production	SOT-23	P	-30	-4.4	-0.9	33	37.5	7.3	1.3
NCE3401E	工业级	Trench	Production	SOT-23	P	-30	-4.4	-0.9	33	37.5	9.5	1.3
NCE60P03R	工业级	Trench	Production	SOT-223	P	-60	-3	-2	148	185	11.3	2.75
NCE60P65K	工业级	Trench	Production	TO-252	P	-60	-65	-2.6	13		75	130
NCE60P18AQ	工业级	Trench	Production	DFN3.3X3.3	P	-60	-18	-1.75	32	44	36.5	40
NCE60P50G	工业级	Trench	Production	DFN5*6	P	-60	-50	-2.6	23		49.8	100
NCE30P25BQ	工业级	Trench	Production	DFN3*3	P	-30	-25	-1.6	8	11.5	42.8	40
NCE40P15Q	工业级	Trench	Production	DFN3*3	P	-40	-15	-1.5	15.5	21	23	25
NCE30P55K	工业级	Trench	Production	TO-252-2L	P	-30	-55	-1.5	6.8	10	70.7	110
NCE30P12BS	工业级	Trench	Production	SOP-8	P	-30	-12	-1.6	9	12.2	41.5	3
NCE40P30K	工业级	Trench	Production	TO-252-2L	P	-40	-30	-1.9	15	24	40.8	60
NCE60P06S	工业级	Trench	Production	SOP-8	P	-60	-6	-2.6	40		46.2	3
NCE60P70G	工业级	Trench	Production	DFN5*6	P	-60	-70	-1.8	11	13	62.1	110
NCE01P13I	工业级	Trench	Production	TO-251	P	-100	-13	-1.9	170		33.1	40
NCE3407E	工业级	Trench	Production	SOT-23	P	-30	-4.3	-1.6	28	38	12.8	1.5
NCE16P07J	工业级	Trench	Production	DFN2*2-6L	P	-6	-7	-0.7	26	34	14.5	2.5
NCE20P08J	工业级	Trench	Production	DFN2*2	P	-20	-8	-0.7	24.5	31	12.8	2.6
NCE20P09S	工业级	Trench	Production	SOP-8	P	-20	-9	-0.7		22	17	3.1
NCE16P40Q	工业级	Trench	Production	DFN3.3*3.3	P	40	-15	-1.5	15.5	21	23	25
NCE20P05J	工业级	Trench	Production	DFN2*2-6L	P	-20	-5	-0.7		65	7	2.5
NCE4435B	工业级	Trench	Production	SOP-8	P	-30	-1.2	-1.6	9	12.2	41.5	3
NCE30P40K	工业级	Trench	Production	TO-252-2L	P	-30	-40	-1.6	7.8	11.5	41.5	40
NCE14P40K	工业级	Trench	Production	TO-252-2L	P	-40	-30	-1.8	11	15	37.4	50
NCE30P85K	工业级	Trench	Production	TO-252-2L	P	-30	-85	-1.6	5.3	7.6	92.5	130
NCE01P35K	工业级	Trench	Production	TO-252-2L	P	-100	-35	-1.8	30	32	118	110
NCE02P20K	工业级	Trench	Production	TO-252-2L	P	-200	-20	-1.8	183	188	122	180
NCE15P30K	工业级	Trench	Production	TO-252-2L	P	-150	-30	-1.8	78	81.5	124	180
NCE035P40GU	工业级	Trench	New	DFN 5*6	N	-40	-130	-1.8	2.8	4.6	158	120
NCE15P30	工业级	Trench	Production	TO-220-3L	N	-150	-30	-1.8	78	81.5	124	180
NCE4614B	工业级	Trench	New	SOP-8	P	-40	-7	1.6	19	35	15.7	2
